Digital Elevator Displays
Typ: PT133E
Seamless Flush Wall Design + Ultra-Thin Panel
LCD Size: 13.3/15.6/18.5/21.5/23.8/27/32/43 inch
1080P Full HD display with 178° ultra-wide viewing angle & accurate RGB color reproduction
Multiple screen sizes (13.3"-43") & flexible horizontal/vertical display modes
Android 7.1/11.0 OS with optional A40, RK3288, RK3566 or RK3399
Dual network support: WiFi (802.11b/g/n) + 10M/100M Ethernet
Cloud-based CMS for remote content management & timed updates
Seamless loop playback + split-screen display functionality
Concealed wiring design + capacitive touch option for smooth operation
Send Inquiry
Product Details of Digital Elevator Displays
Products Overviews
Smart HD doorplate screen
Eight major selling points
Cloud-based intelligent remote publishing
Remote control publishing system in the background, unified management of terminals across the country
Concealed Wiring Design
Specially designed recesses conceal wire routing, resulting in a more sophisticated and aesthetically pleasing appearance.
Precise Touch, Enjoy a Seamless Fingertip Experience
Multi-touch offers rapid response, delivering a smooth and enjoyable new touch experience.
High-definition visual experience
Equipped with an ultra-high-definition display panel featuring a resolution of up to 1080P, it utilises the world's most vibrant RGB colour mode to reproduce colours accurately, resulting in a more high-definition visual experience.
Smart-timed playback
Supports customizable timed power on/off and automatic timed program content updates.
Scene Demonstration
Suitable for offices, conference rooms, hospital clinics, hotels, and other similar settings.
Flexible installation
Available in black and white
Product Dimensions
Product Image
Product Parameters
| System | CPU | A40, RK3288, RK3566 or RK3399 (optional) |
| RAM | 1GB | |
| Storage | 32GB | |
| Operating system | Android 7.1 or Android 11.0 | |
| Network | WiFi | 802.11b/g/n |
| Ethernet | 10M/100M network port | |
| Interface | Card | TF card slot |
| USBx2 | USB host | |
| Micro USB | Micro USB OTG | |
| HDMI | HDMI output | |
| RJ45 | Ethernet port | |
| Serial port | USB interface type, serial port, expand more functions | |
| DC | DC power 12V input | |
| Earphone | 3.5mm stereo headphone output | |
| Media playback | Video format | MPEG-1,MPEG-2,MPEG-4,H.263,H.264,VC1,RV etc.,support up to 4Kx2K(H.264) |
| Audio format | MP3/WMA/AAC, etc. | |
| Image Format | jpeg | |
| Other | Speaker | 2*2W |
| Operating temperature | 0°--40° | |
| Power consumption | 20W | |
| Certification | 3C | |
| OSD language | Multi-language OSD operations, such as Chinese and English | |
| Appendix | user's manual | Standard |
| power cable | Standard |
Best selling
More product specifications
| Product Version | Stand-alone Version (Plug and Play) | Monitor Version | Android Version | PC Version | Raspberry Pi |
| Screen Size | 5/ 7/ 8/ 10.1/ 12.1/ 13.3/ 14/ 15/ 15.6/ 17/ 18.5/ 19/ 21.5/ 24/ 27/ 28/ 32/ 43/ 49/ 55/ 65/ 75/86inch | ||||
| CPU | 一 | 一 | Optional ( RK3566, RK3568, RK3588, RK3399) | Optional ( i5, i7) | 4B |
| RAM | 一 | 一 | 1G (2G/ 4G/ 8G) | 4G (8G/ 16G/ 32G) | 2G (4G,8G) |
| Internal Memory | USB (SD Card, 8 GB) | 一 | 32G (64G/ 128G) | 64G/ 128G/ 256G/ 512G (SSD) | 一 |
| Touch Screen | 一 | Capacitive touch (Optional) |
Capacitive touch (Optional) |
Capacitive touch (Optional) |
|
| Operating System Version | 一 | 一 | Android 7.1 (Android 11.0, Android 13.0) |
Windows7, Windows10, Windows11 | |
| Main functions | 1. Auto-play when powered on. 2. Playlist and splitscreen 3. Both horizontal and vertical screen displays 4. Seamless switching between videos, without a black screen |
HDMI Input (VGA, CVBS, DP optional) | 1. Both horizontal and vertical screen displays 2. Ethernet, WiFi connection, Bluetooth is optional 3. CMS for device management and content update(Free cloud-based CMS) 4. 4G (SIM card)(optional) |
一 | |
| Extensible Function | Motion sensor Push button |
一 | Camera, RFID card reader, Scanner, Printer, POS Bracket | ||
FAQ
Q: Do you have your own enclosure factory?
A: Yes, we have our own enclosure factory, and we have the best structural Engineer. We hope to provide you with the best advertising media solutions and personalised shapes. OEM is also welcome.
Q: What are Digital Elevator Displays used for?
A: Today, digital signage is being used in a variety of applications and settings. Examples are Public information, Internal information, Advertising, Brand Building, influencing customer behaviour, enhancing customer experience, and enhancing the environment.
Q: How long will my Digital Elevator Displays last?
A: The longevity of the digital signage depends on the number of displays, the complexity and amount of content, and the deployment needs.
Q: Do you give any discounts?
A: We are a Manufacturer, so we can give you the best price and best service at the same time.
Q: How long is the warranty time?
A: 1-3 years, except for the human damage and force majeure factor. For optimal maintenance, ensure that the products are used under normal operating conditions.
