Digital Screen Menu Board
LCD Size: 32/43/50 inch
Price Range: $100-$650
Warranty: 1-3 Years
Send Inquiry
Product Details of Digital Screen Menu Board
Product Parameters
| Integrated LED Side-Entry Backlight – Ensures uniform illumination and vivid image quality across the entire display. |
| Ultra-Narrow Front Frame – All four sides feature a consistent, slim bezel design, enhancing visual aesthetics. |
| All-Metal Construction – Built with full metal components for superior durability, anti-theft protection, and vandal resistance. |
| Hundred-Ton Stamped Metal Backplate – Formed using high-pressure stamping to ensure structural rigidity, combined with an elegant curved arc design. |
| One-Piece Backplate Molding – Achieves an ultra-slim profile through integrated mold processing. |
| Front-Mounted Motherboard & Electronics – Designed with a front-assembly structure for simplified manufacturing and easy maintenance. |
| High-Transparency Tempered Glass – Enhances display clarity while providing robust screen protection. |
| LED Light Bar from Certified Supplier – Offers a long lifespan of up to 60,000 hours, ensuring lasting performance and reliability. |
| Built-In Cabling, AC Socket & Rocker Switch – Equipped with pre-installed internal wiring and standard electrical components for convenience. |
| Engineered for HD Video Applications – Optimized for stable, continuous operation with exceptional smoothness in video playback. |
| Runs on Android 7.1 OS with frameless remote publishing software for easy operation. |
| Supports wired/Wi-Fi networks and multi-language OSD menus. |
| Expandable with modules: camera, microphone, NFC, printer, touchscreen, and more. |
| 0°, 90°, 180°, 270° rotation for videos and images. |
| Plays web pages, videos, images, audio, text, time, date, weather, etc. |
| Customizable playback tasks with auto-loop modes (daily, weekly, monthly). |
| Full network publishing features: content management, template design, program preview, grouping, upload/playback, stats, and permissions. |
| Supports local/remote/timed/loop playback, automatic updates, and power scheduling. |
| Equipped with a Full HD 1920×1080 LCD panel, 178° wide viewing angle, high color gamut, and advanced image enhancement technologies. |
| Industrial-grade power system with smart cooling for 24/7 operation; LED dual-chip backlight ensures brightness and energy efficiency. |
| Powered by a quad-core processor with 3D graphics acceleration and 1080P video decoding for smooth performance. |
| Real-time video/audio decoding, supports multiple codecs, and enables centralized control via TCP/IP network for nationwide deployment. |
| Sleek integrated design with metal front frame; supports wall-mounting and horizontal installation. |
| Built with industrial components for better heat dissipation, low power consumption, and long-term reliability. |
Specifications
| Panel | Screen Size | 43 inches new A screen |
| Backlight Type | E-LED | |
| Resolution | 1920*1080 | |
| Brightness | 350cd/㎡±30 | |
| Contrast Ratio | 4000:1 | |
| Response Time | 6.5ms | |
| Pixel Pitch | 0.630mm*0.630mm | |
| Frame Frequency | 60 Hz | |
| Display Size (mm) | L940 x W528 | |
| Color Depth | 1.07B (8-bit) | |
| Lifetime | 50,000 hrs | |
| System | CPU | A40i, quad-core, up to 1.2GHz |
| GPU | Mail-T764 GPU MP4 quad-core GPU Support OpenGL ES1.1/2.0, OpenVG1.1, OpenCL |
|
| Operating System | Android 7.1.1 | |
| RAM | DDR3, default 1GB (2GB optional) | |
| Internal Storage | 32GB | |
| Applications have been installed | APK Installer, Email, Calculator, Browser, Voice Recorder, Calendar, Settings, Clock, Video Player, Search, Contacts, Gallery, Downloads, Camera, Music, Explorer, etc. |
|
| Network | Support RJ45 R/A 100M Ethernet Standard 2.4GHz Wi-Fi (supports optional 5GHz), 802.11b/g/n protocol. 4G (optional), Bluetooth (optional) |
|
| Interface | USB | USB2.0*1, OTG*1 |
| HDMI Out | HDMI out *1 | |
| LAN | 100M Ethernet | |
| WiFi | Support 2.4G WiFi, protocol 802.11b/g/n | |
| Audio Out | 3.5mm audio jack*1 | |
| TF Card | TF Card Slot*1 | |
| RTC | Built-in real-time clock function | |
| IR | Receive a signal from the remote control | |
| Power Supply | Input: 100-240V/50-60Hz AC Output: 12V 1.5A DC |
|
| More interfaces optional | 4G, SIM card slot (optional) | |
| File Format | Video Format | AVI, rm,rmvb, MKV, WMV, MOV, MP4, DAT, PMP, MPEG, MPG, FLV, ASF, TS, TP,3GP, MPG |
| Audio Format | MP3, WMA, WAV, APE, FLAC, AAC, OGG, M4A, 3GPP | |
| Image Format | JPG, BMP, PNG | |
| Power Parameters | Power Supply | 100V~240V/AC, 50/60 Hz |
| Standby Power | ≤0.5W | |
| Power Consumption | ≤130W (varies with screen/motherboard, for reference only) | |
| Environmental Factors | Operating Temperature | 0℃ ~ 40℃ |
| Storage Temperature | -10℃ ~ 60℃ | |
| Operating Humidity | 20% ~ 80% | |
| Storage Humidity | 10% ~ 60% | |
| Maximum Usage Time (Hours×Days) | 24Hours*7days | |
| Structure | VESA Mounting Holes | 4pcs M6 screws, 400mm(L)*400mm(W) |
| Shell Material (Front Frame/Back Shell) | Aluminum Profile/Sheet Metal | |
| Shell Color (Front Frame/Back Shell) | Brushed Silver/Black |
Products Overviews
More product specifications
| Product Version | Stand-alone Version (Plug and Play) | Monitor Version | Android Version | PC Version | Raspberry Pi |
| Screen Size | 5/ 7/ 8/ 10.1/ 12.1/ 13.3/ 14/ 15/ 15.6/ 17/ 18.5/ 19/ 21.5/ 24/ 27/ 28/ 32/ 43/ 49/ 55/ 65/ 75/86inch | ||||
| CPU | 一 | 一 | Optional ( RK3566, RK3568, RK3588, RK3399) | Optional ( i5, i7) | 4B |
| RAM | 一 | 一 | 1G (2G/ 4G/ 8G) | 4G (8G/ 16G/ 32G) | 2G (4G,8G) |
| Internal Memory | USB (SD Card, 8 GB) | 一 | 32G (64G/ 128G) | 64G/ 128G/ 256G/ 512G (SSD) | 一 |
| Touch Screen | 一 | Capacitive touch (Optional) |
Capacitive touch (Optional) |
Capacitive touch (Optional) |
|
| Operating System Version | 一 | 一 | Android 7.1 (Android 11.0, Android 13.0) |
Windows7, Windows10, Windows11 | |
| Main functions | 1. Auto-play when powered on. 2. Playlist and splitscreen 3. Both horizontal and vertical screen displays 4. Seamless switching between videos, without a black screen |
HDMI Input (VGA, CVBS, DP optional) | 1. Both horizontal and vertical screen displays 2. Ethernet, WiFi connection, Bluetooth is optional 3. CMS for device management and content update(Free cloud-based CMS) 4. 4G (SIM card)(optional) |
一 | |
| Extensible Function | Motion sensor Push button |
一 | Camera, RFID card reader, Scanner, Printer, POS Bracket | ||
Best selling
FAQ
Q: Do you have your enclosure factory?
A: Yes, we do have our enclosure factory, and we have the best structural engineer. We hope to provide you with the best advertising media solutions and personalized shapes. OEM is also welcome.
Q: Can be customized?
A: Yes, we have OEM/ODM customer service.
Q: What much the extra cost for your OEM order?
A: Please contact our salesperson about your detailed requests.
Q: Why should you buy us a digital screen menu board?
A: Ningbo Winhi Electronic Co., Ltd., located in Ningbo, China. Our main products are digital signage, digital screen menu boards, monitors, customized audio-video products, etc. We have our designers and R&D team, which enables us to support customized design.
Q: How long is the lead time?
A: 3-5 working days for regular sample orders. 20-45 working days for mass production orders.
