digital signage screens

Name: digital signage screens
Brand: WinHi
SKU: 143983496

Item: 17inch Wall Mount HD Network digital signage screens
Model: PT170A-NW
Price Range: $150-$240
LCD Size: 17 inch 4:3
Resolution: 1024*768
Operating System: Android
CMS software for remote control and content updating
Videos seamless loop, horizontal, vertical and split screen display
Certification: FCC, CE, ROHS
Customized service: LOGO, color, appearance, function
Warranty: 1~3 Years

Send Inquiry

Product Details of digital signage screens

Products Overviews
Product Parameters
More Product
FAQ
Inquiry

Products Overviews

PT170AD-Network_01 PT170AD-Network_02 PT170AD-Network_03 PT170AD-Network_04 PT170AD-Network_05 PT170AD-Network_06

Product Parameters

CPU is a 4-core ARM Cortex-A7, Clocked 1.3GHz, Memory: 1GByte DDR3 1600MHz

Autoplay and loop play

17in digital signage screens support real 1080P HD decode

17in digital signage screens support Seamless Looping

Support Rolling Caption and Split Screen

digital signage screens Support both horizontal and vertical display

Display mode: Video and picture can be rotated 90°/180°/270°.

USB auto copy display content to NAND FLASH 8G

The super time switch function, can auto turn on/off at a specific time

Network Publishing Management, the software is simple and easy to operate

Built-in WIFI module

Specifications

Display	LCD Size	17inch digital signage screens
	Display Area	338x270mm
	Resolution	1024x768
	Luminance	250-300cd/㎡
	Viewing Angle	U20°/D45°/L45°/R45°
	Contrast ratio	800:1
	Display mode	4:3
	Respond Time	8ms
Supported Format	Video Format	MPEG2, AVI, MP4, DIV, TS, TP, TRP, MKV, MOV, DAT, ASF, WMV, RM, RMVB
	Photo Format	JPEG, PNG
	Music Format	MP3, MP2, WMA, WAV
Supported Video Decoding	Max Resolution	1920x1080
	Max Color Depth	24bit
	Max Frame Rate	30frm/s
	Max Code Stream	USB2.0 device:30Mb/s
Supported Audio Decoding	Sampling Rate	32kHz,44.1kHz,48kHz,96kHz
Supported Audio Decoding	Bit Rate	32kbps to 384kbps
I/O	Audio Output	Connect to 8Ω/7W Speaker
	USB Transfer Rate	USB2.0, Max 480Mbps
	Network Interface	100Mbps
	WIFI Interface	100Mbps
	Adaptor	Input: AC 100~240V 50/60Hz

Best selling

1.1_.jpg 1.2

More product specifications

FAQ

Q: Why should you buy from us, not from other suppliers?
A: Ningbo Winhi Electronic Co., Ltd., located in Ningbo, China. Our main products are digital signage screens, advertising media player, monitor, customized audio-video products, etc. we have our own designers and R&D team, which makes us supports customized design.

Q: What does digital signage CMS mean?
A: Digital signage CMS refers to digital signs managed in content management software. The software broadcasts messages such as videos, images, announcements, news, weather, menus, and more to one or many screens.

Q: Can I get some samples?

A: Yes, sure, we are honored to offer you samples to test, but the sample is not free. While to ensure the products are bought correctly and safely, we will offer online testing if you request.

Q: What are the shipment terms and delivery times of your company?

A: Delivery/production time is directly affected by the qty and product model that you choose. And 3-7 extra working days for booking a sea shipment or air flight.

Q: What payment terms do you accept?

A: We accept Paypal, T/T, Alibaba Trade Assurance, Western Union, Wechat, in Cash (RMB or USD)...
